March 20th, 2010 @ 01:40

Last summer, I went to INRIA Sophia Antipolis (INRIA is the French research institute for computer science, basically ; Sophia Antipolis names a group of villages near Nice and Antibes (on the Côte d’Azur) on which are installed quite a lot of technology businesses, among which HP or Amadeus) for a 3 months internship in PLANETE project, under the advisory of Mathieu Lacage, a great software engineer.

Before any extra details, let’s point to the code, the report and the slides. There are also some slides somewhere in the wild which were made for a quick talk given by Mathieu at ns-3 workshop at SIMUtools 2010.

The goal of the internship was to enable the seamless use of multicore parallelization in ns-3 network simulator to speed up simulations.
The obvious idea behind this project is that with all the trends on going more and more towards highly multicore architectures even for personal computers, such a change would possibly allow large speedups without having to directly throw a lot of hardware in the balance and without requiring most likely complicated configurations from the user.

Our goal was to make theses changes entirely transparent for both developers (i.e. those working on improving the ns-3 framework — routing stuff, devices handling…) and users (i.e. those using ns-3 to simulate their protocols…).

Before going into the optimization details, let’s mention the basic idea of the algorithms that we used for the synchronisation of the execution units (the cores, in our case), algorithms which are part of the conservative synchronization algorithms class (as opposed to optimistic algorithms class).
We first tried a message-passing based approach, namely the Chandy, Misra, Bryant algorithm. The whole idea in this algorithm is that each node knows how far in the future it can avance without any risk of simulation desynchronization. This is based on knowing the physical transfer delays, plus the current date of the neighboring nodes ; date which is passed through recurrent messages. This way, under certain conditions (namely that no link has a null transfer time), the simulation will safely advance.
We found out that this approach would lead to no performance gain due to the amount of messages which have to be passed compared to the actual amount of stuff done per time unit.
We then used a barrier-based synchronization algorithm : at each iteration, a global maximum date is determined, based on the current date of each node and the physical transfer delays (again). All the node are thus allowed to process events up to this date, then wait at the barrier, and then go to the next iteration when everyone has reached the barrier. The actual barrier implementation is a fun part, which is described in the report. From a trivial semaphor implementation to a fully optimized, tree-shaped implementation, performance gains of over a 100 fold can be observed.

One of the usual challenges when doing parallel computing is to define a proper partition of what each execution unit does. For instance, when working on a network of nodes (which are computers, routers…), which nodes should be handled by which execution unit ? Since we don’t want to ask the user about what he thinks would be the best, and since we can’t just use topology clues to make a good partitionning (because it also depends on the actual dynamics of the network, which we can’t predict), we had to use a dumb solution and make it smart. The solution we found there was to have both dedicated and global nodes : a given percentage of nodes is dedicated to each execution unit, while a global pool of nodes remains undedicated. When an unit has finished processing it’s own dedicated nodes, it starts picking nodes from the global pool and process them. This way, these units won’t waste their time waiting for other units which have to handle more complicated nodes in their dedicated set, thus requiring more processing time just for the local set.

Now you are going to ask, why not just use a global pool and let all the units directly pick nodes to process from there ? The whole problem is that this global list must be protected, two threads just can’t pick stuff from it at the same time — this would lead to awful memory corruptions, and probably more. Consequently, we need to use either mutexes (i.e. locks) or atomic operations to modify the list. Atomic operations are cheap compared to locks, and yet they are still at least 10 times slower than normal operations. This justifies the whole dedicated + global pools approach.

Now, there were more thread safety problems. While most of them were easily disarmed for minor performances loss (such as disabling free list or caches), there was still a major issue : reference counting. Indeed, in order to be as user-friendly as possible, ns-3 provides (and heavily uses) a reference counting system to ease memory handling for users. The whole problem there is that the counters might be accessed concurrently by two threads at once. What happens when a thread references an objet at microseconds before another thread unreferences it ?
An usual i++ operation is usualy done by taking i from memory to a register, adding 1 to it and putting it back to memory. Now, if the original reference count was 1, we could have the first thread taking i = 1 from memory, the second one taking i = 1 from memory, remov 1, putting i = 0 back into memory, then figuring i == 0 and trashing the objet, then the first threading adding 1 locally, and putting i = 2 back into memo… wait, this memory has been unallocated. Game over.
Again, a possible solution is to use atomic operations. Oh right, they are awfully expensive. Don’t care, let’s try, there must not be that much ref/unrefs going around there. And then… ow, actually, we just catched a plain 100% runtime increase.
While we fixed some of the stupidities that lead to such horrible increases, the problem was still on.
We tried to use thread local storage to maintain a per-thread reference count, but this did not really solve the problem, just helped.
We finally tried to use thread local buffers of Ref/Unref operations, which would be batch-ran by a single thread. This lead to nice performance improvements over the previous solutions, but if I remember correctly under certain unknown conditions the code would badly crash or eat all the memory. Urgh.

Still, in some conditions, I still managed to get over 20% performance improvement with 8 threads (iirc).

The conclusion of all this is that multithreaded programming is definitely not a trivial problem and that converting an existing software to gain from multithreading is not that easy. For more information, numeric data and all, check the report.

Now, I have had no time since middle September to work on the issue, but I know Mathieu has. It’d be awesome to have some news from him here… To be continued, hopefully.
